MS Pipes Manufacturers in India
Mild steel black pipes, also known as MS Black Pipes, are perfect for welding into pipes, tubes, and other types of tubing because they are not galvanised. It is one of the least expensive metals on the market and, if used in a well-maintained setting, can last up to 100 years. Black pipes are currently one of the most popular in the building and general engineering industries due to the excellent quality steel used in their production. We always keep plenty of seamless and welded mild steel pipe in stock in our warehouse. We provide the materials whenever needed to all gatherings, large and little. Mild steel pipe is something we export everywhere in the world. We are able to deliver our items to any location in the world because to our extensive network and strong relationships with supply chain management.
MS Pipes Manufacturing
Our product range includes a wide range of gi pipes forhand pump.
- Higher durability and longevity
- Weld consistency and integrity
- Amenable to rigorous fabrication
- Strict adherence to quality standards
- Greater resistance to corrosion
Technical Specifications :
| Nominal Bore | Outside Diameter | Light (A-Class) Thickness Weight | Medium (B-Class) Thickness Weight | Heavy (C-Class) Thickness Weight | |||||
| Inch | mm | Inch | mm | mm | kg/mtr | mm | kg/mtr | mm | kg/mtr |
| 1/8″ | 3 mm | 0.406 | 10.32 | 1.80 | 0.361 | 2.00 | 2.65 | 0.493 | |
| 1/4″ | 6 mm | 0.532 | 13.49 | 1.80 | 0.517 | 2.35 | 0.407 | 2.90 | 0.769 |
| 3/8″ | 10 mm | 0.872 | 17.10 | 1.80 | 0.674 | 2.35 | 0.852 | 2.90 | 1.02 |
| 1/2″ | 15 mm | 0.844 | 21.43 | 2.00 | 0.952 | 2.65 | 1.122 | 3.25 | 1.45 |
| 3/4″ | 20 mm | 1.094 | 27.20 | 2.35 | 1.410 | 2.65 | 1.580 | 3.25 | 1.90 |
| 1″ | 25 mm | 1.312 | 33.80 | 2.65 | 2.010 | 3.25 | 2.440 | 4.05 | 2.97 |
| 1.1/4″ | 32 mm | 1.656 | 42.90 | 2.65 | 2.580 | 3.25 | 3.140 | 4.05 | 3.84 |
| 1.1/2″ | 40 mm | 1.906 | 48.40 | 2.90 | 3.250 | 3.25 | 3.610 | 4.05 | 4.43 |
| 2″ | 50 mm | 2.375 | 60.30 | 2.90 | 4.110 | 3.65 | 5.100 | 4.47 | 6.17 |
| 2.1/2″ | 65 mm | 3.004 | 76.20 | 3.25 | 5.840 | 3.65 | 6.610 | 4.47 | 7.90 |
| 3″ | 80 mm | 3.500 | 88.90 | 3.25 | 6.810 | 4.05 | 8.470 | 4.85 | 10.1 |
| 4″ | 100 mm | 4.500 | 114.30 | 3.65 | 9.890 | 4.50 | 12.10 | 5.40 | 14.4 |
| 5″ | 125 mm | 5.500 | 139.70 | – | – | 4.85 | 16.20 | 5.40 | 17.8 |
| 6″ | 150 mm | 6.500 | 165.10 | – | – | 4.85 | 19.20 | 5.40 | 21.2 |
MS Pipes Grades :
| EN 10219 S235JRH | EN 10219 S275J0H | EN 10219 S275J2H | EN 10219 S355J0H | EN 10219 S355J2H | ASTM A500 Gr A |
| ASTM A500 Gr B | ASTM A500 Gr C | IS4923 YST210 | IS4923 YST240 | IS4923 YST310 | |
Get EnquiryWhy Choose GI Pipes
01
Longer Life
02
Green-Pro Certified
03
Superior Finish
